Side Lifter Trailer 40FT

Container Side Lifter Trailer

Container side lifter is a special semi-trailer that is used to lift and transport containers. Also known as a container side loader, this trailer is basically used for container transport.

The lift modules could be easily slid smoothly inwards or outwards for 20’ and 40' container positions.

20FT position:

40ft Position:

Lifting Cranes– also known as crane modules. These are hydraulically powered cranes that lift the cargo/container either from the ground, another vehicle, a loading dock, a railway wagon or straight from the top of another container placed on the ground.

The container side lifter trailers have 37T-45T capacity. You can learn more details in the sheet.

Overall Dimension: 14100mm*2500mm*4000mm

Tare Weight: 13900kg

Wheelbase: 8000mm+1350mm+1350mm

Suspension: Three axle leaf spring suspension with equalizer beam.

Tire: 11.00R20, 12pcs

Axle: 13T capacity each, three axles.

Brake: Dual lines pneumatic brake system.

Main Beam: I shape, Mild Alloy Q345B by Automatic submerged arc welding.

Container: one 20ft container or one 40ft container.

Max. lifting capacity: 37000kg

Max. working range: 4000mm

Max. stabilizer outreach: 3200mm

Control: Remote control
